Measuring range

0-100% O₂

Signal Output ⁽¹⁾

8-13 mV

Response Time 90%

9 Seconds

Accuracy Full Scale ⁽²⁾

+ 1%

Accuracy FS Over Operating Temperature ⁽³⁾

+ 5%

Drift (% Signal Month) ⁽²⁾

< 1%

Linearity ⁽²⁾

+ 1%

Humidity non-condensing

0-99% RH

Temperature Coefficient

Compensated

Operating Temperature

0-45°C

Operating Pressure

Constant 5-30 PSIG

Flow Rate

.1-10 LPM

Expected Life ⁽¹⁾

60 Months

Storage ⁽⁴⁾

0 to 40°C

Warranty ⁽⁵⁾

18 Months

Electrical Connections

Modular Jack 6P4C

Packaging

Polyetylene bag in

3” x 3” x 1.5” paper box

Recommended Storage

< 6 months
